26
Hardware items
10
🟢 In place / boxed
4
🔵 Stored elsewhere
4
🟠 Partial / loc TBD
5
🟡 Ordered
3
🚩 Needs purchase
Sources: Shell Supply & Armory sheet (Dormitory Shade Hardware block) cross-checked 8/20 against Jade's SHD1 + SHD2 tote labels.
🟢 physically verified in place/box · 🔵 stored off-tote (kitchen, 51' trailer, on-playa) · 🟠 partial counts or location to confirm · 🟡 ordered, awaiting arrival · 🚩 still needs purchase decision.
Full Hardware Accounting 26 items · Aluminet (Living) dormitory
| Item | Category | Qty | Stored | Status | Spec & Notes |
|---|---|---|---|---|---|
| Forged Eye Bolt 3/8" x 6" | Support | 16 | On Posts | 🟢 IN PLACE | Drop forged, hot galv, 2.5" thread w/ nut, WLL 1200lb · 2 per post ×6 posts = 12 + 4 spare |
| Eye Nuts 3/8" | Support | 16 | On Posts | 🟢 IN PLACE | Hot dip galv forged steel, 16 UNC tap, 5/16" bail · 2×6 posts = 12 + 4 spare |
| 3/8" Galvanized Washers | Washers | 32 (1×100pc set) | On Posts | 🟢 IN PLACE | 4 per post (one each side, both bolts) · 6×2×2=24 + 8 spares · David: 'hats on stakes' |
| Aluminum Swage Sleeves 3/16" | Swages | ×100 | SHD1 tote | 🟢 IN SHD1 | For aircraft cable — 4 per cable end · ⚠️ David: MUST be 3/16" NOT 3/8" (wrong size was returned) · matches SHD1 label 'Aluminum Swage Sleeves ×100' |
| Galvanized Aircraft Cable 3/16" 7x19 | Cabling | 500 ft reel | SHD1 tote | 🟢 IN SHD1 | 500ft reel · matches SHD1 label 'Aircraft Cable 500ft' |
| Galvanized Wire Rope Thimble 3/16" | Cabling | 18 | SHD1 tote | 🟢 IN SHD1 | Standard duty · 2 per cable × 7 cables = 14 + 4 spare |
| Swaging Tool (crimper/cutter) | Tool | 1 | Tool Storage in Kitchen | 🔵 KITCHEN TOOL STORAGE | AMZCNC wire rope crimping kit 3/64"–3/16" · crimps swages + cuts wire |
| Screw Pin Anchor Shackles 3/8" (D-ring) | Structural | 30 ordered (6 to buy) | SHD1 tote | 🟠 PARTIAL — 20 IN SHD1 | Load rated screw pin anchor shackle · ✓ SHD1 label: '3/8" D Ring Shackle ×20' · 1/2" wrong size returned, 3/8" re-ordered · David: 'not needed (1 received)' |
| Safety/Seizing Wire | Structural | 1 spool | Jeff Temon 51' trailer | 🔵 51' TRAILER (Jeff Temon) | WCS .032 stainless safety lock wire · contact Jeff Temon re: 51' trailer storage · David: 'not needed' |
| Stake Remover (lightweight) | Tool | 1 | TBD | 🟠 RECEIVED — LOC TBD | Bon Tool 14-145 steel puller · David: get soon, sometimes backordered |
| Big Ass Stake Puller | Tool | 1 | — | 🚩 FLAG — NOT BOUGHT | Pioneer alloy steel lever stake puller · RSS $216.80 · David link: pioneersupplyco.com |
| Circus Stakes 1"x40" double-head 2840DH | Stakes | 30 | — | 🚩 FLAG — NOT BOUGHT | 3 per corner post ×4 + 1 per side ×2 = 14 needed + 10 spares... David: need 30 ACTS4212 |
| 2" Heavy Duty Ratchet Straps w/ Loops | Heavy Duty | 20 | — | 🟡 ORDERED | 3,335lb WLL, 11,000lb breaking — loops NOT s-hooks, special order · David to specify |
| Load Rated Screw Pin Anchor Shackle 3/8" (neon green) | Cabling | 70 | — | 🟡 ORDERED | neon green per David · David: 'will figure out with david' |
| Main Ratchet Straps | Heavy Duty | — | — | 🟡 ORDERED | from Shippers Supply |
| Attic Bars (E-track load bars) | Structural | 2 | — | 🟡 ORDERED | Aluminum E-track shoring beam 102" · stores big poles in roof of trailer |
| 3/16" Zinc Plated Spring Hooks | Small Bits | ×100 (need 790) | SHD1 tote | 🟠 PARTIAL — 100 IN SHD1 | 250pc × 5 packs needed (790 total) · ✓ SHD1 label: 'Zinc Plated Spring Hooks ×100' · ⚠️ ~690 SHORT |
| Paracord neon green (loops + template) | Cord | 1000' | — | 🟡 ORDERED | NOT 1/4" nylon — neon green YES per David |
| Truck Bed Tie-Downs | Small Bits | ×320 (32 packs) | SHD1 tote | 🟢 IN SHD1 | stainless tie-down anchors · ✓ SHD1 label: 'Truck Bed Tie Down ×320' · sheet note said 130 received + 190 missing — SHD1 label shows FULL 320 now ✓ |
| Hot Knife | Tool | 1 | TBD | 🟠 RECEIVED — LOC TBD | ROMECH electric adjustable · cuts/seals rope + webbing |
| Post Bases | Support | 8 | ON PLAYA (David) | 🔵 ON PLAYA (David) | carpet square or 4"×4" plywood w/ rebar · David: 'I have these on playa already' |
| Center Poles/Bases | Stakes | 8 | David | 🔵 PURCHASED (David) | · purchased from David |
| Larger Spring Hooks | Small Bits | 40 | — | 🚩 FLAG | Alps doc suggested, type TBD · David: 'not really needed but I could specify' |
| 12" Spike Nails | Stakes | ×3 boxes | SHD2 tote | 🟢 IN SHD2 | Grip-Rite 12" x 3/8" exterior galv spike nails, 50lb boxes · ✓ SHD2 label: '12" Spike Nails ×3 boxes' · David confirmed: 'yes, spike nails' |
| Awning Door Roller Balls | Small Bits | ×4 | SHD1 tote | 🟢 IN SHD1 | · ✓ SHD1 label: 'Awning Door Roller Ball ×4' — NOT on sheet, found in SHD1 |
| Blanket Pins for Patio Lights | Small Bits | ×50 | SHD1 tote | 🟢 IN SHD1 | · ✓ SHD1 label: 'Blanket Pins for Patio Lights ×50' — NOT on sheet, found in SHD1 |
